Flexible enough for any application and perfect for homes, offices, decks and porches. Our design team works closely with customers to ensure their handrail is exactly what they envision for their project.

Rails and Posts

  • Extruded Aluminum Pipe ASTM B429, Aluminum alloy 6061-T6.  Finish AA M10C22A41.  Posts – 1 ½ inch IPS Schedule 80.  Rails – 1 ½ inch IPS Schedule 40
    • Flanges
      • Sand cast from high tensile aluminum-magnesium alloy 535.0
      • Supplied with anodize finish.7mil minimum thickness.
      • Design – Fittings shall be the type, which fastens directly to the pipe by means of and internal/external, reverse knurl, cup point, hexagon socket set screw.
      • All anchoring hardware shall be 300 series stainless steel.
      • Flanged that include a bearing plate will not be accepted.
  • Fasteners
    • All fasteners to be 302 or 304 stainless steel.
    • No pop rivets of sheet metal screws will be accepted.
  • Infill material
    • Pickets: ¾” aluminum rod
  • Finish
      • Aluminum: Anodized
